Specifications
Synth voice features
• 6 × FM based Machines
• 1 × Assignable LFO per track
• 1 × Assignable velocity modulation per track
• Storage space for up to 60,000 presets
Sequencer
• 6 × Audio tracks (all of which may be used as MIDI tracks as well)
• Elektron sequencer with up to 64 steps
• Unique length and scale settings per track
• Parameter locks
• Micro timing
• Trig conditions
• Assignable retrig
• Real-time or grid recording of notes and parameters
• 96 × Projects
• 96 × Patterns per Project
• Send & master effects
• Delay and reverb send FX
Hardware
• 6 × Velocity sensitive pads
• Class compliant USB audio 2.0
• 1 × 1/4” stereo headphone jack
• 2 × 1/4” impedance balanced audio out jacks
• 1 × Hi-speed USB 2.0 Micro B port
• 3.5 mm dual polarity TRS MIDI In, Out/Thru jacks
• 128 × 64 pixel LCD screen
• 48 kHz, 24-bit D/A converters
• Power inlet: Center positive 3.5 × 1.35 mm barrel jack, 5 V DC, 1 A
• Battery In: Center positive 5.5 × 2.1 barrel jack, 4–10 V DC
• 2 × slots for attaching Power Handle BP-1 (battery pack to be released at a later date)
Physical specifications
• W 270 × D 180 × H 39 mm (10.7” × 7.1” × 1.6”) (including knobs and feet)
• Weight: approximately 0.80 kg (1.8 lbs)
Included in the box
• Power Supply PSU-4
• Micro USB Cable USB-2
• 2 × MIDI adapter (5-pin DIN to 3.5mm TRS mini jack)
